Bourdon tube pressure gauge with output signal For the process industry, safety version, NS 100 and 160

Models PGT23.100, PGT23.160
Bourdon tube pressure gauge with output signal
For the process industry, safety version, NS 100 and 160

Nominal size:100mm,160mm
Process connection:G 1/2 B
Connection location:lower mount
Measuring system    :stainless steel
Case:    stainless steel with solid baffle wall and blowout back
Accuracy class:    class 1.0
Output signal:    4 ... 20 mA, 2-wire  ,Unit of outer Scale    bar
Electrical connection:    L-Plug DIN EN 175201-804 6-pin + PE sidewise

Applications
Acquisition and display of processes
Output signal 4 ... 20 mA for the transmission of process values to the control room
Easy-to-read, analogue on-site display needing no external power
Process industry: Chemical industry, petrochemical industry, oil and gas, power generation, water and wastewater

Special Features
No configuration necessary due to “plug-and-play”
Signal transmission per NAMUR
Measuring ranges 0 ... 0.6 bar to 0 ... 1,600 bar
Safety version S3 per EN 837

Two-wire pressure transmitter Models PGT23.100, PGT23.160
Alarm point setting: full range range can be set
Mechanical accuracy: 1.0%FS
Sensor accuracy: 0.25% FS
Operating voltage: 24VDC
Medium: Gas and liquid compatible with 316 stainless steel
Operating temperature: -40℃~70 ℃
Storage temperature: -40℃~70℃
Sampling rate: 5 times/second
Signal connection: 4mA-20mA current output can be provided
Upgrade intelligent: with Hart protocol
Protection class: IP 65
Shell material: 316 stainless steel
Measuring range:
-0.1~0.15Mpa,
0 ~ 0.4 Mpa,
0~1Mpa,
0~6Mpa ,
0~ 12 Mpa ... 60 Mpa
The two-wire pressure transmitter combines mechanical field display and intelligent remote transmission system. The process pressure can be displayed and the signal is transmitted to the central control room. And widely used in petroleum, chemical, natural gas,! Steelmaking and other industries. This product is intrinsically safe and explosion-proof. And can also be equipped with a chemical seal isolation to measure the strong corrosive liquid viscosity.
